BetaScan Elite S1
A lightweight high-speed blue laser 3D scanner for fast, fine and deep-hole scanning, quickly capturing stable 3D data from industrial parts.
BetaScan Elite S1 3D Scanner
BetaScan Elite S1 高速・精細・深穴スキャンを1台に統合
High-speed, fine and deep-hole scanning in one device, capturing metrology-grade 3D data with stability.
Highest Accuracy
0.020mm
Highest Scan Rate
8,300,000 measurements/s
Max Scan Area
650mm×550mm
Volumetric Accuracy
0.015mm+0.035mm/m
Highest Resolution
0.01mm
Multiple Scan Modes
Fast scan Fine scan Deep-hole scan
最高精度
0.020 mm
最大スキャンレート
毎秒7,100,000回計測
最大スキャン幅
650mm × 550mm
最高体積精度
0.015 mm + 0.025 mm/m
最高解像度
最大0.01 mm
複数のスキャン方式に対応
高速スキャン、精密スキャン、深穴スキャン
技術仕様
| Model | BetaScan S1 | BetaScan Elite S1 | |
|---|---|---|---|
| Scanning Mode | High-speed scanning | 26 crossed blue laser lines | 50 crossed blue laser lines |
| Precision scanning | 17 parallel blue laser lines | 17 parallel blue laser lines | |
| Deep hole scanning | 1 single blue laser line | 1 single blue laser line | |
| Accuracy | up to 0.020mm | ||
| Measurement rate | 6,000,000 measurements/s | 8,300,000 measurements/s | |
| Scanning area | up to 650mm×550mm | ||
| Laser class | Class II (Eye safe) | ||
| Resolution | up to 0.01mm | ||
| Volumetric accuracy | 0.015mm+0.035mm/m 0.015mm+0.025mm/m (working with photogrammetric scale bar) | ||
| Working distance | 300mm (200mm fine mode) | ||
| Depth of field | 550mm | ||
| Output formats | stl, ply, obj, txt etc. | ||
| Operating temperature | -10°C to 40°C | ||
| Product dimensions | L×W×H：340×145×70mm | ||
| Product weight | 1.15kg | ||
| Interface type | USB 3.0 | ||
| Minimum computer requirements | OS: Windows 10 or later (64-bit required) GPU: NVIDIA GTX/RTX series (e.g., RTX 4060 or higher) VRAM: 8 GB or more CPU: Intel Core i7-13700H or better RAM: 32 GB or higher | ||
※ According to the VDI/VDE 2634 part 3 standard and the JJF 1951-2021 calibration specification for optical three-dimensional measurement systems based on structured light scanning.
